Expandable and Flexibility

2 loops (expandable up to 6 loops on NFU-7000 and 14 loops on NFU-7000-L)
-254 addresses per loop
-BACnet support
-Real time 3D graphical monitoring and control available

Networkability

-Up to 63 panels

Serviceablility

-Large 16 x 40 character graphic LCD display
- 6,000 event-logs; 1,000 for alarm related events and 5,000 for all events

Large System Capacity

- 12 Ampere power supply is available by one control panel
- Outputs for NAC devices: 1.7A@24VDC x 4ch (Class A or B)
-Aux Power: 1.7A@24VDC

Other specifications

- Dimensions: H710 x W430 x D146 mm(NFU-7000),
H950 x W795 x D200 mm(NFU-7000-L)
-Power supply: AC120V 60Hz / AC240V 50Hz, 4A/2A
-Printer interface: RS-232C
